Siemens CU240B-2 Installation Instructions

140
75
100
385
400
140
85
110
230
120
150
465
480
495
517
M8
M10
M10
 
A5E31327192A AC
Wall mounting FSF for fixing: 4 x M6 ( ), 3 Nm
Wall mounting FSD for fixing: 4 x M6 ( ), 3 Nm
Wall mounting FSE for fixing: 4 x M6 ( ), 3 Nm
Line Connection
example
SINAMICS G120
Installation Instructions
A5E31327192A AC,
Edition 05/2013
Line Filters
FSD ... FSF
Filter Identification
Electrical
characteristics
Mechanical characteristics
Cable cross sections and tightening
torques
L1 / L2 / L3 PE
Order no.
Frame Size Current Puls frequency
Min … max Min
Weight Lateral distance
A
kHz
mm
2
Nm
mm
2
Nm kg cm
6SL3203-0BE27-5BA0 FSD 72 4 … 16 16 … 50 6 … 8 16 6 ±0,3 7.6 0
6SL3203-0BE31-1BA0 FSE 105 4 … 16 16 … 50 6 … 8 35 10±1,0 11.9 0
6SL3203-0BE31-8BA0 FSF 204 4 … 8 35 … 150 9 … 11 50 10±1,0 21.7 5
The filters are suitable for SINAMICS G120 Power Modules. For details refer to catalog D31 and to
the Hardware Installation Manual of the Power Module.
Mounting plate
Mounting plate
Mounting
plate
L1
L2
L3
