B Bidirectional
V Power supply
X10 power supply
Connector designa‐
tion:
X10; 3-pin terminal block
Table 4-4 Assignment of connector X10
Pin Signal name Signal type Meaning
1 P24
V
24 V potential
2 M24 Ground 24 V
3 SHIELD Shield connection
Ethernet X20/X21
Connector designation: X20, X21
Connector type: RJ45 socket
Table 4-5 Assignment of connectors X20, X21
Pin Name Type Meaning
1 TX+ I Transmit +
2 TX- I Transmit -
3 RX+ O Receive +
4 N.C. - Not assigned
5 N.C. - Not assigned
6 RX- O Receive -
7 N.C. - Not assigned
8 N.C. - Not assigned
Feedrate override rotary switch X30
Connector designation: X30
Connector type: 2 x 5-pin male connectors, acc. to IEC603-13 with coding
Table 4-6 Assignment of connector X30
Pin Name Type Meaning
1 N.C. - Not assigned
2 N.C. - Not assigned
Interfaces
4.3 Machine control panels
ERGOline Stage 3
26 Manual, 02/2015, 6FC5397-4FP40-0BA0
