Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
IB 8
2)
DT 8 DT 7 DT 6 DT 5 DT 4 DT 3 DT 2 DT 1
IB 9
2)
DT 16 DT 15 DT 14 DT 13 DT 12 DT 11 DT 10 DT 9
IB 10 KT-IN8 KT-IN7 KT-IN6 KT-IN5 KT-IN4 KT-IN3 KT-IN2 KT-IN1
IB 11
3)
SS-3(24) SS-2(22) SS-1(14) SS-0(12) - - - KT-IN9
IB 12 - - - - - - - -
IB 13 - - - - - - - -
1)
Inverse signals
2)
DT1 to DT16 - direct keys
3)
Keyswitch X50
Table 4-18 Input image for handwheel data
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
IB 14 Handwheel 1 counter status
(16-bit signed, least significant byte equals byte n+14)
IB 15
IB 16 Handwheel 2 counter status
(16-bit signed, least significant byte equals byte n+16)
IB 17
Within the SINUMERIK control, the handwheel data is processed directly by the NCK and is
not available to the PLC.
Default key assignments
The DMG customer keys are not labeled.
Figure 4-8 Milling key assignment
Interfaces
4.3 Machine control panels
ERGOline Stage 3
34 Manual, 02/2015, 6FC5397-4FP40-0BA0
