Siemens FC924 Installation Instructions

6
Siemens Industry, Inc. A6V10356958_en--_n
Smart Infrastructure
Table 2: Limitations and Restrictions per CAN/ULC-S527 3
rd
Ed. Amd 1 cl. 7
Notice to
Users, Installers, Authorities Having Jurisdiction (AHJ) and Other Involved Parties
This product incorporates field
-
programmable software. In order for the product to compl
y with the requirements in
CAN/ULC-S527, Standard for Control Units for Fire Alarm Systems, certain programming features or options must be
limited to specific value or not used at all as indicated below.
3
Program Feature or Options
Permitted in
CAN/ULC-
S527? (Y/N)
Possible Setting
s
Setting Permitted in
CAN/
UL
C
-
S527
Ability to change the volume for
the sounder on the FACP
Y
Adjustment of the sounder volume on
the Operating Unit Menu ranges from
Loud to Max to Low to Min to
Bypassed
Setting of the
Sounder Volume
must
be greater than " Bypassed " setting.
Default must be set to Max
Global Access Point (GAP) using
Ethernet connection
*
Y
Ability to connect the FACP network
using the Ethernet connection on the
Operating Unit to connect to the
FCNET
When used with DesigoCC
Management Station, connection
must be in the same room within 20
feet and installed in rigid conduit.
Panel control functions using
"Desigo View" (Remote User
Interface)
*
N
Ability to connect the FACP network
using the Ethernet connection on the
Operating Unit to permanently connect
to the Desigo View.
Not Allowed
Ability to set FDOOT441 and
FDOOTC441 detectors sensitivity
Y
FDOOT441 and FDOOTC441
detectors can be configured in the
programming tool: 2.50%/ft , 3.00%/ft ,
2.50%/ft + Verified , 3.00%/ft + Verified,
3.5%/ft and 3.5%/ft + Verified
Only the
Selectable Alarm Threshold
Setting Profiles permitted are:
2.50%/ft , 3.00%/ft , 2.50%/ft +
Verified , 3.00%/ft + Verified
Ability to set the FDOOTC441
detectors to CO level limit
Y
FDOOTC441 detectors can be
configured in the programming tool to
define CO level limits in the range of
20ppm – 600ppm (in 10ppm
increments)
Minimum selection for
CO level
limits must be 30ppm
Ability to configure the FDCIO422
for Class A inputs with Open and
Short circuit supervision
N
FDCIO422 inputs can be configured
for Class A with Open and Short circuit
supervision.
Not Allowed
Ability to set the FDCIO422 device
to multiple Input Filter Time
Setting
Y
FDCIO422
Input Filter Time Setting
can be configured in the programming
tool : 0.25s, 0.5s, 1s, 2.5s,5s, 10s,
20s, 45s, 60s, 90s, 120s, 180s, 210s,
240s
Acceptable FDCIO422
Input Filter
Time Setting are:
0.25s , 0.50s , 1s
Ability to set the FDCIO422 device
to multiple Output Pulse Mode
Time Setting
Y
FDCIO422
OutputPulse Mode Time
Setting can be configured in the
programming tool: 1s, 2s, 3s, 5s, 10s,
20s.
Acceptable
Output Pulse Mode Time
Setting are: 10s, 20s.
Ability to set the FDCIO422 device
to Normally Closed inputs for
Class A & Class B wiring
N
FDCIO422
Input Type
can be
configured to Normally Closed
Not Allowed
