Undertaking modernization
4
Step 2: Replacing the control panel and changing over to FDnet-Ex/C-NET-Ex protocol
Migration to the following protocols can take place, depending on the control panel
being used:
FDnet-Ex: Use the multiple protocol detector FDOOT241-A9-Ex
FDOOT241
-A9-Ex
FDnet-Ex
FDOOT241
-A9-Ex
FDOOT241
-A9-Ex
FDOOT241
-A9-Ex
FDM223-
Ex
FDnet
FDnet
FDnet-Ex
FDCL221-
Ex
FDCL221-
Ex
Non-Ex Area
Ex Area
C-NET-Ex: Use the multiple protocol detector OOH740-A9-Ex
OOH740
-A9-Ex
C-NET-Ex
OOH740
-A9-Ex
OOH740
-A9-Ex
OOH740
-A9-Ex
FDM223-
Ex
C-NET
C-NET
C-NET-Ex
FDCL221-
Ex
FDCL221-
Ex
Non-Ex Area Ex Area
If the national and regional regulations in your country permit automatic fire
detectors and manual call points to be operated on a single stub, all detector
types can be operated on a joint stub.
