3.3.3 Connection terminal DBZ1190-AB
 Auxiliary terminal for connecting cables
 For T-branches of additional cabling for cable
shielding, detector heating units, sounder base,
external alarm indicators, etc.
 For wire diameters of 1 … 2.5 mm
2
 3-pin
 Order no.: BPZ:4942340001
3.3.4 Dummy detector FDX291
F
D
X
2
9
1
S
5
4
3
1
9
-
F
2
-
A
1
 To protect the detector base from dirt
 External labelling for identification
 Does not open the contact in the detector base
 Compatible with:
– Detector base FDB2xx
– Sounder base FDSB29x
 Order no.: S54319-F2-A1
