Annex technical data
33
Building Technologies 007025_i_en_--
Fire Safety & Security Products 07.05.2010
Tone No. 5: Pulse tone
Sound
intensity
Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 75 80 80 74 72 77 77 80 80 77 79
1 (low) 66 66 70 70 65 64 68 68 70 71 68 68
Tone No. 6: Intermittent
Sound
intensity
Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 75 79 79 74 71 77 77 79 79 76 76
1 (low) 65 65 69 70 64 64 68 68 70 70 67 67
Tone No. 7: Continuous
Sound
intensity
Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 77 77 80 81 75 74 79 79 80 81 78 78
1 (low) 67 67 76 72 66 64 69 69 71 72 69 69
Tone No. 8: Alternating
Sound
intensity
Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 77 81 82 75 72 68 68 81 81 77 77
1 (low) 66 68 72 73 66 64 69 69 72 72 68 68
Tone No. 9: Intermittent
Sound
intensity
Horizontal Vertical
15° 45° 75° 105° 135° 165° 15° 45° 75° 105° 135° 165°
0 (max.) 75 76 79 80 75 72 78 78 80 80 78 78
1 (low) 65 66 70 70 66 64 68 69 70 70 69 69
