en Shelf supports
22
3.
Pull the rail out towards the front until the retainer at
the back unhooks.
4.
Remove the pull-out rail.
5.
Clean the pull-out rail.
→"Cleaning products", Page17
17.4 Attaching the pull-out rail
Note:The pull-out rails only fit on the right or left. Make
sure when you fit them that you can pull them out to-
wards the front.
1.
Insert the pull-out rail between the two bars.
2.
Push the retainer in between the lower and the
upper bar.
3.
Keep the PUSH tab pushed in and swing the pull-
out rail inwards until the front retainer is located
between the two bars .
‒ Release the PUSH tab.
a The retainer clicks into place.
4.
Pull the pull-out rail out as far as it will go and slide
it back in.
