Siemens iQ700 HB974GL 1B Series User Manual

Familiarising yourself with your appliance en
7
Familiarising yourself with your appliance
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
1
2
1
Display
The display shows the current adjustment val-
ues, options or notes.
Use the and buttons to navigate in the dis-
play.
→"Display", Page7
2
Buttons
You can use the buttons to set various func-
tions directly.
→"Buttons", Page7
4.2 Display
The display is divided into different areas.
Status bar
The status bar is at the top of the display.
You can carry out actions depending on the setting
step.
In addition to the text information, you can see the cur-
rent status of different functions using symbols.
Symbol Meaning
Time, e.g.
"12min10s"
Display of the current time-setting op-
tions.
→"Time-setting options", Page13
Timer is activated.
→"Setting the timer", Page14
The childproof lock is activated.
→"Childproof lock", Page17
The appliance door is locked due to the
cleaning function or childproof lock.
→"Pyrolytic activeClean cleaning func-
tion", Page22
→"Basic settings", Page18
Symbol Meaning
Wi-Fi signal strength for HomeConnect.
The more lines of the symbol are filled,
the better the signal.
If the symbol is struck through , there
is no Wi-Fi signal.
If there is an "x" at the symbol , there
is no connection to the HomeConnect
server.
→"HomeConnect ", Page19
Remote start with HomeConnect is ac-
tivated.
→"HomeConnect ", Page19
Remote diagnostics with HomeCon-
nect for maintenance is activated.
→"HomeConnect ", Page19
The oven light is on or off.
→"Lighting", Page8
Settings area
The settings area is shown in tiles.
The individual tiles show you the current selection op-
tions and settings that have already been implemented.
To select a function, press the corresponding tile.
Information is also shown in tiles.
To scroll to the left or right if there are several tiles, use
the navigation buttons and ⁠.
Possible symbols in tiles
Symbol Meaning
Scroll if there is a lot of content in the
tile.
Decrease or increase the adjustment
value.
Reset the adjustment value.
Close the tile.
Note:A blue dot or a blue star in a tile indicates that a
new function, a new favourite or an update was down-
loaded to your device using the HomeConnect app.
4.3 Buttons
You can use the buttons to directly select various func-
tions.
Button Function
Switch the appliance on or off.
→"Basic operation", Page12
Start or pause the operation.
→"Basic operation", Page12
Go back one setting.
Select the timer.
→"Setting the timer", Page14
Press and hold for approx. 4 seconds:
Activate or deactivate the childproof
lock.
→"Childproof lock", Page17

Siemens iQ700 HB974GL 1B Series Specifications

General

Type	Built-in oven
Energy Efficiency Class	A+
Capacity	71 liters
Cleaning System	Pyrolytic self-cleaning
Connectivity	Home Connect
Color	Black
Number of Cooking Levels	5
Cooling Fan	Yes
Child Lock	Yes
Door Hinge	Bottom
Control	Touch control
Heating Methods	4D hot air, hot air grilling, pizza setting, keep warm
Temperature Range	30 °C - 300 °C
Dimensions	595 x 594 x 548 mm
