2/24
Building Technologies Division CC1N7153en
21.09.2016
Supplementary documentation
Product type Type of documentation Documentation number
LOK16 (For burner controls used in
connection with burners for continuous
operation)
Data Sheet N7785
Warning notes
To avoid injury to persons, damage to property or the environment, the following
warning notes must be observed!
Do not open, interfere with or modify the unit!
All activities (mounting, installation and service work, etc.) must be performed by
qualified staff
Before making any wiring changes in the connection area, completely isolate the
plant from mains supply (all-polar disconnection). Ensure that the plant cannot be
inadvertently switched on again and that it is indeed dead. If not observed, there is
a risk of electric shock hazard
Ensure protection against electric shock hazard by providing adequate protection
for the burner control’s connection terminals
Each time work has been carried out (mounting, installation, service work, etc.),
check to ensure that wiring is in an orderly state and make the safety checks as
described in «Commissioning notes»
Press the lockout reset button only manually (applying a force of no more than 10
N), without using any tools or pointed objects
Do not press the lockout reset button on the unit or the remote reset button (input
21) for more than 10 seconds since this will damage the lockout relay in the unit
Fall or shock can adversely affect the safety functions. Such units must not be put
into operation, even if they do not exhibit any damage
For safety reasons – self-test of the flame supervision circuit, etc. – at least one
controlled shutdown must take place every 24 hours
Mounting notes
Ensure that the relevant safety regulations are complied with
Connect the earthing lug inside the terminal base to burner ground using a screw
with a lockwasher
Note!
In applications involving air heaters (WLE), or in the case of oil burners with a
maximum throughput of >30 kW/h, removing wire link B is not permitted.
Installation notes
Always run high-voltage ignition cables separately, with the greatest possible
distance to the unit and to other cables
Live and neutral conductors must not be mixed up
Install switches, fuses, earthing, etc., in compliance with local regulations
Make certain that the maximum permissible current rating of the connection
terminals will not be exceeded
The insulation on internal wiring which is subjected to the mains voltage must
withstand the electrical stress occurring during correct use
