6/16 CC1N7421E December 04, 1998 Landis & Staefa Division
Operating voltage AC 230 V +10 % / -15 % Weight
- Burner control approx. 158 g
Mains frequency 50 Hz -6 %...60 Hz +6 % - Plug-in base AGK11 approx. 80 g
- AGK65... approx. 12 g
Power consumption 12 VA - AGK66... approx. 12 g
Primary fuse max. 10 A (slow) Degree of protection IP 40
Mounting position optional Max. cable length terminals 8 and 10 20 m
Environmental conditions
Input current at terminal 12 max. 5 A
Transport
IEC 721-3-2
Climatic conditions class 2K2
Identification code to EN 298
Temperature range -40...+60 °C
LMG21... / LMG22... F T L L X N
Humidity < 95 % r.h.
LMG25... F T C L X N
Mechanical conditions class 2M2
Operation
IEC 721-3-3
CE conformity
Climatic conditions class 3K5 According to the directives of the European Union
Temperature range -20...+60 °C Electromagnetic compatibility EMC
Humidity < 95 % r.h. 89 / 336 EEC incl. 92 / 31 EEC
Condensation, formation of ice and ingress of
water are not permitted!
Directive for gas appliances 90 / 396 EEC
Terminal rating At cos
ϕ
≥
0.6 At cos
ϕ
= 1
- Terminal 3 max. 2.7 A
(15 A during max. 0.5 s)
max. 3 A
- Terminals 4, 5 and 7 max. 1.7 A max. 2 A
- Terminal 10 max. 1 A max. 1 A
Technical data
LMG2...
