8 Display and operating unit AZL5 22.05.2018
2) End of a successful adaption
After adaption, the relevant characteristics are displayed.
By pressing the Selection buttons, the P-, I- and D-parts as well as the acquired loop
delay time «Tu» are displayed:
A d a p t i o n o k
P - P a r t ( X p )
X 2 5 . 0 %
C o n t i n u e w i t h < >
A d a p t i o n o k
I - P a r t ( T n )
4 0 0 s
C o n t i n u e w i t h < >
A d a p t i o n o k
D - P a r t ( T v )
3 5 s
C o n t i n u e w i t h < >
A d a p t i o n o k
D e l a y T i m e ( T u )
1 0 s
C o n t i n u e w i t h < >
3) Canceling the adaption
If the load controller was not able to select a suitable loop, it stops the adaption and
displays the following text.
If an adaption in progress is manually canceled by pressing Esc, the following text also
appears:
A d a p t i o n
c a n c e l l e d
C o n t i n u e w E S C
The system changes to normal operation. In that case, the previous PID parameters are
maintained.
