Foreword
1FK7 Synchronous Motors
vi Configuration Manual (PFK7), 10/2005 Edition, 6SN1197-0AD06-0BP1
Table -3: ESDS informatio n and instructions
Caution
Motors should be connected-up according to the circuit diagram provided. They must not be
connected directly to the three-phase supply because this will damage them.
SIMODRIVE and SIMOVERT MASTERDRIVES drive units with AC motors are subject, as
part of the type test, to a voltage test corresponding to EN 50178. According to EN 60204-1,
Section 19.4, while electrical equipment of industrial machines are being subject to a voltage
test, all of the SIMODRIVE and SIMOVERT MASTERDRIVES drive unit connections must be
disconnected/withdrawn in order to avoid damaging the SIMODRIVE and SIMOVERT
MASTERDRIVES drive units.
Note
SIMODRIVE and SIMOVERT MASTERDRIVES drive units with motors fulfill, when opera-
tional and in dry equipment rooms, the Low-Voltage Directive 73/23/EEC.
SIMODRIVE and SIMOVERT MASTERDRIVES drive units with motors fulfill, in the configura-
tions specified in the associated EC Declaration of Conformity, EMC Directive 89/336/EEC.
