7ML19985CX01 Milltronics ILE-61 – INSTRUCTION MANUAL Page 3
Sensing Plate
Construction
• 304 (1.4306) stainless steel
Options
• 316 (1.4404) stainless steel
• UHMW polyurethane or Ceramic Tile abrasion resistant lining
• Synergistic polymer or PFA coating for low cohesion and friction
LVDT Conditioner Card
Power
• ± 5 V DC (typically from Siemens Milltronics integrator)
Ambient Temperature
• –40 to 50 °C (–40 to 122 °F)
Input
• 0 to 1.0 V from LVDT
Output
• 0 to 50 mV to Milltronics SF 500 (maximum 300 m (1000 ft) separation between
Conditioner Card and integrator)
Approvals
•CE
Enclosure
• NEMA 4 (remote mounted unit)
Cable
For connection between LVDT Conditioner Card and Integrator
•Belden®
1
8404, 4 conductor, shielded 20 AWG (0.5 mm
2
) or equivalent, 150 m (500 ft)
maximum
• Belden 9260, 6 conductor, shielded 20 AWG (0.5 mm
2
) or equivalent, 300 m (1000 ft)
maximum
For connection between LVDT and remote LVDT Conditioner Card,
or directly between LVDT and Integrator
• Belden 8404, 4 conductor, shielded 20 AWG (0.5 mm
2
) or equivalent, 300 m (1000 ft)
maximum
1.
Belden is a registered trademark of Belden Wire & Cable Company.
