7ML19985CX01 Milltronics ILE-61 – INSTRUCTION MANUAL Page 5
Viscous Damper
1. Remove the 2 damper cover shipping screws. The damper cover will be held up by a
spring.
2. If necessary, top up the damper (to near overflowing) with the damping fluid
supplied.
3. Store the damper cover shipping screws, remaining damper fluid, and filler bottle for
future use.
Interconnection
Non-Hazardous Unit without LVDT Conditioner Card
* See note below for Encapsulated (Hazardous-rated) LVDT color codes.
Note: The damper must be full and free of air bubbles with the damper cover in
the UP position during flowmeter operation.
Note: Ground shield at Integrator only.
filler bottle
filler plug
shipping screws
damper cover
to LVDT
G
R
N
B
L
K
Y
E
L
B
L
U
R
E
D
S
I
G
–
–
C
O
M
E
X
C
–
E
X
C
+
to integrator
(LVDT connection)
flowmeter
terminal
block
*For Encapsulated LVDT (hazardous)
YEL = WHITE
BLU = ORANGE
GRN = YELLOW
cable
clamp
