Page 2 Milltronics ILE-61 – INSTRUCTION MANUAL 7ML19985CX01
Specifications
Operating Range
• 0 to 20 t/h (0 to 22 STPH) min., 0 to 300 t/h (0 to330 STPH) max.
Product
• fine powder to 25 mm (1")
Product Temperature
• -40 to 232 °C (-40 to 450 °F)
Ambient Temperature
• -40 to 60 °C (-40 to 140 °F)
Accuracy
• ± 1 % of full scale, higher accuracy with linearizing function of integrator
Repeatability
•± 0.2 %
Range Spring
• selected to suit application
Construction
• dust-tight cast aluminum frame with fiberglass rear cover
Mounting
•base mount
Sensor Type
• LVDT (linear variable differential transformer)
LVDT Excitation
• 2.50 V AC @ 2.9 kHz (supplied by Flowmeter Integrator or LVDT Conditioner Card)
LVDT Output
• 0 - 0.75 V AC @ 2.9 kHz
Damping Fluid
• 10 - 100 cm
2
/s (1000 - 10 000 cs) silicone, (Dow Corning 200 recommended)
Options
• Epoxy paint, synergistic polymer, or PFA coating of external aluminum casting
surfaces
• Epoxy painted mild steel or stainless steel rear cover
Approvals
•CE
• Optional CSA. Class I, Groups C and D; Class II, Groups E, F, and G
