Appendix
Getting Connected to MindSphere
Getting Started, 05/2018 83
Ambient conditions
Ambient temperature during operation
Ambient temperature during
operation
0 °C up to 60 °C
min. 0 °C
max. 60 °C
Ambient temperature during storage/transportation
min. -20 °C
max. 60 °C
Relative humidity
Relative humidity Tested according to IEC 60068-2-78, IEC 60068-2-30: Operation: 5% to 80% at 25
°C (no condensation), Storage: 5% to 95% at 25 °C (no condensation)
Vibrations
Vibration load in operation Tested to DIN IEC 60068-2-6: 10 Hz to 58 Hz: 0.075 mm, 58 Hz to 200 Hz: 9.8 m/s²
(1 g)
Shock testing
Shock load during operation Tested according to IEC 60068-2-27: 150 m/s², 11 ms
Software
MindConnect Software Pre-installed MindConnect Software
Dimensions
Width 191 mm
Height 100 mm
Depth 60 mm
