Siemens Building Technologies
Fire Safety
P/N 315-048692-212
Supervisory Supervisory Annunciation
When a supervisory is detected, the System causes the SUPERVISORY LED on the
MKB to flash, the System’s internal audible to sound, and the display on the MKB to
display the event in the following format:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SIEMENS BUILDING TECHNOLOGIES
SUP CUSTOM MESSAGE
SUP CUSTOM MESSAGE
IN
IN
Example shown is Canadian Display
12:01:22 Dec 31, 02
ALR=000, SUP=002, TBL=000, SEC=000
SUP CUSTOM MESSAGE
IN
40 Characters
1-001
002
11:59:59 Dec 31, 02
(002 / 002)
Figure 6
SUPERVISORY Event Screen With More Info Key Pressed
In addition, the System responds to supervisories with programmed output functions.
In Figure 6, 1-001 represents the address of the device reporting the supervisory.
002 on Line 14 in the More Info area (Lines 13-15) tells you that this is the second
(and the most recent) of two supervisories received. The status information shown in
Line 10 reports the total of alarms, supervisories, troubles, and security conditions.
If your System includes a printer, it prints a message from two to four lines long
similar to the following:
SUPERV 1-1 11:59:59 Dec 31, 20xx
#2 [custom message], [device type]
