Siemens OpenAir GEB141.1P

Technical Instructions OpenAir GEB Series Enhanced Rotary Non-Spring Return Damper Actuators
Document Number A6V12029156
December 16, 2021
Page 16 Siemens Industry, Inc.
Non-spring Return
Floating
24 Vac
1. Check Operation:
a. Apply a control signal (24 Vac) to wires 1 (red) and 6 (violet).
b. Allow the actuator shaft coupling to rotate from 0 to 90°.
c. Stop applying a control signal to wires 1 (red) and 6 (violet).
d. Apply a control signal (24 Vac) to wires 1 (red) and 7 (orange).
e. Allow the actuator shaft coupling to rotate from 90° to 0°.
2. Check Feedback:
a. Set the DMM dial to ohms.
b. Connect wires P1 and P2 to the DMM.
The DMM should indicate a resistive value.
c. Apply a control signal (24 Vac) to wires 1 (red) and 6 (violet).
The reading of the DMM should increase.
d. Stop applying a control signal to wires 1 (red) and 6 (violet).
e. Connect wires P2 and P3 to the DMM. The DMM should indicate a resistive value.
f. Apply a control signal (24 Vac) to wires 1 (red) and 7 (orange).
The reading of the DMM should increase.
3. Check the Auxiliary Switch A:
a. Set the DMM dial to ohms (resistance) or continuity check.
b. Connect wires S1 and S3 to the DMM.
The DMM should indicate an open circuit or no resistance.
c. Apply a control signal (24 Vac) to wires 1 (red) and 6 (violet).
The DMM should indicate contact closure as the actuator shaft coupling reaches the setting of
switch A.
d. Stop applying a control signal to wires 1 (red) and 6 (violet).
e. Connect wires S1 and S2 to the DMM.
The DMM should indicate an open circuit or no resistance.
f. Apply a control signal (24 Vac) to wires 1 (red) and 7 (orange).
The DMM should indicate contact closure as the actuator shaft coupling reaches the setting of
switch A.
4. Check the Auxiliary Switch B:
a. Set the DMM dial to ohms (resistance) or continuity check.
b. Connect wires S4 and S6 to the DMM.
The DMM should indicate an open circuit or no resistance.
c. Apply a control signal to wires 1 (red) and 6 (violet).
The DMM should indicate contact closure as the actuator shaft coupling reaches the setting of
switch B.
d. Stop applying a control signal to wires 1 (red) and 6 (violet).
e. Connect wires S4 and S5 to the DMM.
The DMM should indicate an open circuit or no resistance.
f. Apply a control signal (24 Vac) to wires 1 (red) and 7 (orange).
DMM should indicate contact closure as the actuator shaft coupling reaches setting for
switch B.
