Siemens OpenAir GEB141.1P

Technical Instructions OpenAir GEB Series Enhanced Rotary Non-Spring Return Damper Actuators
Document Number A6V12029156
December 16, 2021
Page 2 Siemens Industry, Inc.
Product Numbers
Table 1.
Product
Number
Operating
Voltage
Control
Cable
Built-in Control
Options
24 Vac/Vdc ±20%
100 to 240 Vac
Modulating (0 to 10 Vdc)
On/Off & Floating
Plenum
Standard
Position Feedback
Feedback Potentiometer
Dual Auxiliary
Switches
Offset and Span
Input Signal Selectable 0 – 10 Vdc or 2
-10 Vdc
GEB141.1P
●
–
–
●
●
–
–
–
–
–
–
GEB141.1U
●
–
–
●
–
●
–
–
–
–
–
GEB142.1U
●
–
–
●
–
●
–
●
–
–
–
GEB146.1U
●
–
–
●
–
●
–
–
●
–
–
GEB161.1P
●
–
●
–
●
–
●
–
–
–
●
GEB161.1U
●
–
●
–
–
●
●
–
–
–
●
GEB164.1U
●
–
●
–
–
●
●
–
●
●
●
GEB166.1U
●
–
●
–
–
●
●
–
●
–
●
GEB341.1U
–
●
–
–
–
●
–
–
–
–
–
GEB361.1U
–
●
●
–
–
●
●
–
–
–
●
Specifications
Power Supply
Operating voltage 24 Vac 20%; 24 Vdc 20%
100 to 240 Vac 10%
Frequency 50/60 Hz
Power consumption
Running: Holding:
GEB14x 2.3 VA/1.1W 0.5 W
GEB16x 2.5 VA/1.2W 0.65 W
GEB 34x 4 VA/1.6W 0.9W
GEB36x 3.4 VA/1.3W 0.6W
Equipment rating Class 2, in accordance with UL/CSA
Class III per EN 60730
Control Signal
Input signal (wires 8-2) GEB16x
Voltage-input 0 (2) to 10 Vdc (max. 35 Vdc)
Input resistance >100K ohms
Feedback signal
Position output signal (wires 9-2) GEB16x
Voltage-output 0 to 10 Vdc
Maximum output current 1 mA
Function
Running torque 177 lb-in (20 Nm)
Maximum torque 310 lb-in (35 Nm)
Nominal runtime for 90° opening or closing 150 seconds
Nominal angle of rotation 90°
Maximum angular rotation 95° +/- 2°
