Siemens OpenAir GEB141.1P

OpenAir GEB Series Enhanced Rotary Non-Spring Return Damper Actuators Technical Instructions
Document Number A6V12029156
December 16, 2021
Siemens Industry, Inc. Page 3
Mounting
Shaft size 1/4 to 3/4-inch (6.4 to 20.5 mm) dia.
1/4 to 1/2-inch (6.4 to 13 mm) square
Minimum shaft length 3/4-inch (20 mm)
Housing
Enclosure NEMA 1
IP54 according to EN 60 529
Material Die cast aluminum alloy
Gear lubrication Silicone free
Ambient conditions
Ambient temperature
Operation -25°F to 130°F (-32°C to 55°C)
Storage and transport -40°F to 158°F (-40°C to 70°C)
Ambient humidity (non-condensing) 95% rh
Agency certification
UL UL60730
cUL CAN/CSA E60730
Conformity
Low voltage directive 2006/95/EC
Product safety: Automatic electrical controls EN 60 730-2-14
for household and similar use (Type 1)
Electromagnetic compatibility (EMC) 2004/108/EC
Emissions for all models EN61000-6-3
Auxiliary features
Control signal adjustment
Offset (start point) Between 0 to 5 Vdc
Span Between 2 to 30 Vdc
Dual auxiliary switches
AC rating 24 to 250 Vac
AC 6A resistive,
AC 2A general purpose
DC rating 12 to 30 Vdc
DC 2A
Switch Range
Switch A 0 to 90° with 5° intervals
Recommended range usage 0 to 45°
Factory setting 5°
Switch B 0 to 90° with 5° intervals
Recommended range usage 45 to 90°
Factory setting 85°
Switching hysteresis 2°
Feedback potentiometer (GEB 142.1U) 0 to 1000 ohm <10 mA
Voltage UL/cUL-Class 2 (SELV/PELV for CE)
