Siemens OpenAir GIB13.1 Series Technical Basics

12/44
Siemens Rotary actuators without spring return GBB/GIB..1 CE1Z4626en
Smart Infrastructure Non-spring return actuators 2019-11-28
2.6 Setting and operating elements
4626Z05
A
B
12
11
10
9
6
4
3
2
1
15
90°
7
5
8
PUSH
Uo
2
4
0 1
3
5
D
U
30
2
15
10
5
20
25
16
Legend
1 Housing
2 Rotary angle scale 0°...90°
3 Potentiometer to adjust the span
4 Potentiometer to set the offset
5 Rotary direction switch
6 Connecting cable for power and
positioning signal
7 Connecting cable for auxiliary switches
8 Gear train disengagement button
9,10 Setting shafts for auxiliary switches A
and B
11 Position indicator
12 Self-centering shaft adapter
13 Locking ring for shaft adapter
14 Adapter for position indicator
15 Mounting bracket
16 Connecting cable for feedback
potentiometer
Fo
r long damper shafts
For short damper shafts
4636Z03
13 12
4636Z05
11
4636Z02
12
13
14
4636Z04
11
Direction of rotation Rotary direction switch Direction of rotation Function
Counter-clockwise
4626Z02
Clockwise
(factory setting)
Direction of rotation
Actuator
Arrangement of shaft
adapter
Rotary direction switch
(legend pos. 5)
GBB/GIB16..1
