Siemens OpenAir GIB13.1 Series Technical Basics

8/44
Siemens Rotary actuators without spring return GBB/GIB..1 CE1Z4626en
Smart Infrastructure Non-spring return actuators 2019-11-28
2.2 Type summary
The following table shows the options for the actuator types.
GBB/GIB..
131.1E 135.1E 136.1E 331.1E 335.1E 336.1E 161.1E 163.1E 164.1E 166.1E 161.1E/MO
Mode of control Three-position
(see section 2.1 “Application”)
Modulating control
Modbus RTU
Operating voltage
AC 24 V
X X X X X X X X
Operating voltage
AC 230 V
X X X
Positioning signal input Y
DC 0...10 V X X
DC 0...35 V
with characteristic
function
X X
Modbus RTU X
Position indicator
U = DC 0...10 V X X X X
Modbus RTU X
Feedback potentiometer
1kW
X X
Self-adaptation of rotary
angle range
X
Auxiliary switches (two) X X X X X X
Rotary direction switch X X X X
Powerpack
(two actuators)
X X X X X X X X X X
For functional enhancements of the actuators, the following accessories are available:
External auxiliary switches (1 Switch) ASC77.1
External auxiliary switches (2 Switches) ASC77.2
Rotary/linear set for duct mounting ASK71.1
Rotary/linear set for frame mounting ASK71.2
Rotary/linear set with lever ASK71.3
Rotary/linear set with lever and mounting plate ASK71.4
Universal lever ASK71.9
Bracket for powerpack ASK73.1
Self-aligning bracket for powerpack ASK73.2
Special shaft adapter ASK74.1
Weather shield for rotary actuator ASK75.1
Data sheet for accessories and spare parts N4699
Accessories, spare parts
Accessories
