Technical specifications
4.3 Module-specific data
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA
39
Article number
6ES7972-0BA12-0XA0
6ES7972-0BB12-0XA0
Dimensions
Width
15.8 mm
15.8 mm
Height
64 mm
64 mm
Depth
35.6 mm
35.6 mm
Weights
Weight (without packaging)
36 g
45 g
Scope of supply
Delivery quantity in pieces
1
1
PROFIBUS bus connector plug up to 1.5 MBaud
• 6ES7972-0BA30-0XA0
Article number
6ES7972-0BA30-0XA0
General information
Product description
PROFIBUS bus connector, RS 485, Fast Connect, without
programming port, 30°
Suitability for use
For connecting PROFIBUS stations to the PROFIBUS bus cable
Interfaces
PROFIBUS DP
•
Transmission rate, min.
9.6 kbit/s
•
Transmission rate, max.
1.5 Mbit/s
Degree and class of protection
IP degree of protection
IP20
Standards, approvals, certificates
UL approval
Yes
Ambient conditions
Ambient temperature during operation
• min.
-25 °C
• max.
60 °C
Accessories
belongs to product
SIMATIC DP
Connection method
Design of electrical connection for network compo-
nents/terminal equipment
9-pin sub D connector
Programming device socket
No
FastConnect cable design
Yes
Number of electrical connections for PROFIBUS lines
2
Number of electrical connections for network components
and terminal devices
1
Mechanics/material
Type of terminating resistor
No integrated terminating resistor
Interlock design
Screwed joint
Outgoing feeder type
30 degree cable outlet
Material of housing
plastic
Material property
•
Silicone-free
Yes
Strain relief
Yes
