Siemens PROFIBUS - Device Description; 6 ES7972-0 Bx12-0 XA0

PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA
7
Device description
3
3.1 6ES7972-0Bx12-0XA0
The following provides you with product information about the PROFIBUS bus connector
with/without PG socket up to 12 MBaud 6ES7972-0Bx12-0XA0:
You can use the PROFIBUS bus connector to
• Connect stations with an electrical 9-pin D-sub interface according to IEC 61158-2 directly
to the SIMATIC NET PROFIBUS lines.
• Electrical segments or individual stations can be connected to the Optical Link Module
(OLM, OBT).
• Stations or programming devices are connected to the repeater.
More information
You can find more information about the PROFIBUS bus connector in the SIMATIC NET
PROFIBUS manual. The manual can be obtained at the nearest offices of your Siemens
representative or free of charge on the Internet at the following link
(http://support.automation.siemens.com/WW/view/en/35222591).
Maintenance
The PROFIBUS bus connector requires no maintenance. In the event of a fault, contact your
Siemens representative responsible for spare parts/repairs:
Services (https://support.industry.siemens.com/cs/ww/en/sc/2154)
