Technical specifications
4.3 Module-specific data
PROFIBUS bus connector
42 Equipment Manual, 02/2021, A5E50543113-AA
Article number
6ES7972-0BA52-0XA0
6ES7972-0BB52-0XA0
Accessories
belongs to product
SIMATIC DP
SIMATIC DP
Connection method
Design of electrical connection for network compo-
nents/terminal equipment
9-pin sub D connector
9-pin sub D connector
Programming device socket
No
Yes
FastConnect cable design
Yes
Yes
Number of electrical connections for PROFIBUS lines
2
2
Number of electrical connections for network components
and terminal devices
1
1
Mechanics/material
Type of terminating resistor
Resistor combination inte-
grated and connectable via
slide switch
Resistor combination inte-
grated and connectable via
slide switch
Interlock design
Screwed joint
Screwed joint
Outgoing feeder type
90 degree cable outlet
90 degree cable outlet
Material of housing
plastic
plastic
Material property
• Silicone-free
Yes
Yes
Strain relief
Yes
Yes
Dimensions
Width
15.8 mm
15.8 mm
Height
59 mm
59 mm
Depth
35.6 mm
35.6 mm
Weights
Weight (without packaging)
36 g
45 g
Scope of supply
Delivery quantity in pieces
1
1
