Technical specifications
4.3 Module-specific data
PROFIBUS bus connector
Equipment Manual, 02/2021, A5E50543113-AA
45
Article number
6ES7972-0BA70-0XA0
6ES7972-0BB70-0XA0
Mechanics/material
Type of terminating resistor
Resistor combination inte-
grated and connectable via
slide switch. Isolation func-
tion: When resistor is con-
nected, outgoing bus is
disconnected
Resistor combination inte-
grated and connectable via
slide switch
Interlock design
Screwed joint
Screwed joint
Outgoing feeder type
90 degree cable outlet
90 degree cable outlet
Material of housing
plastic
plastic
Material property
•
Silicone-free
Yes
Yes
Strain relief
Yes
Yes
Dimensions
Width
15.8 mm
15.8 mm
Height
72 mm
72 mm
Depth
36.4 mm
36.4 mm
Weights
Weight (without packaging)
34 g
45 g
Scope of supply
Delivery quantity in pieces
1
1
