Siemens PXC....D PXC...-E.D + PXA40-… – Automation stations modular series CM1N9222en_03
Building Technologies 16 Mar 2010
Type summary
Automation stations
for connection of TX-I/O-modules via island bus
Up to 200 data points Over 200 data points
Automation station BACnet / LonTalk
PXC100.D PXC200.D
Automation station BACnet / IP
PXC100-E.D PXC200-E.D
Compatibility
Operating units Type Data sheet
Local operating unit
PXM10
CM1N9230
Operating unit
PXM20
CA1N9231
Operating unit for Ethernet
PXM20-E
CM1N9234
Connection cable (to connect to operator units PXM10 or
PXM20 and to download firmware)
PXA-C1 --
TX-I/O device Type Data sheet
Digital input module 8 or 16 I/O points
TXM1.8D, TXM1.16D CM2N8172
Universal module without / with local operation and LCD
TXM1.8U, TXM1.8U-ML CM2N8173
Super universal mod. without / with local operation and LCD
TXM1.8X, TXM1.8X-ML CM2N8174
Relay module without / with local operation
TXM1.6R, TXM1.6R-M CM2N8175
Resistance measuring module (for Pt100 4-wire)
TXM1.8P CM2N8176
Power supply module 1.2 A, Fused 10A
TXS1.12F10 CM2N8183
Bus interface module, Fused 10A
TXS1.EF10 CM2N8183
Island bus expansion module
TXA1.IBE CM2N8184
TX OPEN module
TXI1.OPEN CM1N8185
System controllers
for integration via extension modules PXX...
System controller BACnet / LonTalk
PXC00.D
System controller BACnet / IP
PXC00-E.D
Extension module L
ONWORKS
for integration of DESIGO RXC and LonMark compatible 3rd party devices (together with PXC00….D)
Type Data sheet
Integration of max. 60 devices
Integration of max. 120 devices
PXX-L11
PXX-L12
CM1N9282
