QMX3... Wall-mounted sensors and room operator units for KNX PL-Link, KNX S-mode and KNX LTE-Mode CM2N1602en_07
Siemens Building Technologies 2017-05-22
Display
Type
Segment LCD
Information displayed depends on the application in the
room automation station.
–
Room temperature, humidity, CO
2
–
Setpoint adjustment
–
Control mode
–
Manually selected fan speed
–
Control sequence
–
Scenes (LED next to the button)
–
etc.
Ports/interfaces
Type of port between room automation station and room
operator unit
KNX / PL
-Link
Baud rate
9.6 kbps
Standard KNX plug
Wire diameter0.8 mm, max. 1.0 mm
(solid conductors only)
Cable type
Solid conductors 2-core, twisted pair
Single cable length (from room automation station to room
operator unit)
<1000 m
Cables must comply with KNX specifications, see TRA Install. manual, CM111043
*)
Housing protection
Protection standard as per EN 60529
IP 30
Protection class
Insulation protection class
III
Ambient conditions
IEC 721
Normal operation
Transport
Environmental conditions
Class 3K5
Class 2K3
Temperature
0...50 °C
– 25...70 °C
Humidity
< 85 % rh
< 95 % rh
Mechanical conditions
Class 3M2
Class 2M2
Standards and directives
EU conformity (CE)
CM2T1602xx
*)
compliance
UL916
compliance
Part 15 of the FCC rules
CSA compliance
C22.2 No 205
– Signal equipment
C22.2 No 0 – General Requirements
RCM Mark conformity (EMC)
AS/NZS 61000
-6-3
The product environmental declaration CM2E1602
*)
contains data on environmentally compatible product
design and assessments (RoHS compliance, materials composition, packaging, environmental benefit,
disposal)
Color
Front housing Models QMX3.Pxx
Models QMX3.Pxx-1BSC
Titanium white similar to RAL9010
Black similar to RAL9005
Weight [g]
QMX3.
P02
P30
P34
P37
P40
P70
P74
Operator unit
91
84
122
124
85
97
132
Base plate
20
20
20
20
20
20
20
Packaging
64
64
64
64
64
64
64
Total
175
168
206
208
169
181
216
*)
The documents can be downloaded from http://siemens.com/bt/download.
Notes on FCC rules
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
− Reorient or relocate the receiving antenna.
− Increase the separation between the equipment and receiver.
− Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
− Consult the dealer or an experienced radio/TV technician for help.
NOTICE
FCC warning
