Siemens RDF302 - Parameters of the Service Level

44 / 58
Siemens RDF302 Basic documentation CE1P3079en
Building Technologies 07 Dec 2011
3.13.3 Parameters of the "Service level"
Parameter
Name Factory setting Range
Service level
P01
Control sequence
2-pipe: [0…3]
1 (Cooling only)
4-pipe: [2…4]
4 (Heating & Cooling)
0 = Heating only
1 = Cooling only
2 = Manual Heating or Cooling
3 = Auto Changeover
4 = Heating & cooling
P02
Mode selection by user via
operating mode button 1 (Comfort, Protection)
1 = Comfort, Protection
2 = Comfort, Energy Saving,
Protection
P04
Selection of °C or °F °C
0 = °C
1 = °F
P05
Sensor calibration 0.0 °C
-3...3 °C
P06
Standard temperature display 0 (Room temperature)
0 = Room temperature
1 = Setpoint
P07
Additional user information 0 (no display)
0 = No display
1 = Temperature in °C/°F
2 = Outside temperature
(via Modbus)
3 = Time of day (12 h, via Modbus)
4 = Time of day (24 h, via Modbus)
P08
Comfort basic setpoint 21 °C 5...40 °C
P09
Minimum setpoint limitation in
Comfort (Wmin
Comf
)
5 °C 5...40 °C
P10
Maximum setpoint limitation
in Comfort (Wmax
Comf
)
35 °C 5...40 °C
P11
Setpoint of heating in Energy
Saving
15 °C OFF, 5 °C…Wcool
Eco
P12
Setpoint of cooling in Energy
Saving
30 °C OFF, Wheat
Eco
…40 °C
P13 *
Electrical heater in cooling
mode
ON
OFF = disabled
ON = enabled
P14
Button lock
(Press operating mode button
for 5 seconds to lock or
unlock the buttons) 0 (Disabled)
0 = Disabled
1 = Auto lock
2 = Manual lock
*
)
Parameter P13 and P54 is only displayed for application "2-pipe with electric
heater".
All temperature settings are in increments of 0.5 °C.
Note:
