Siemens RDG User Manual

10
Product Application Standalone
Standalone
with
7-day time
program
Communicating
KNX
Wall-mounted units: RDG
RDG100…
Versatile thermostats with
control output signal (ON/OFF)
or mod. (PWM or 3-pos.).
– 2-pipe (ON/OFF, PWM or 3-pos)
– 2-pipe with electrical heater
– FCU: (ON/OFF, PWM or 3-pos)
– el. heater: (ON/OFF, PWM or 3-pos.)
– 2-pipe and radiator
– FCU: (ON/OFF, PWM or 3-pos)
– radiator: (ON/OFF, PWM or 3-pos.)
– 4-pipe (ON/OFF, PWM and/or 3-pos)
– 4-pipe with electrical heater
– FCU: (ON/OFF, PWM and ON/OFF, PWM or 3-pos)
– el. heater: (ON/OFF)
– 2-stage heating or cooling
– FCU: (ON/OFF, PWM or 3-pos)
RDG100 RDG100T RDG100KN
RDG110
Robust thermostat with
relay outputs (SPDT) for
ON/OFF – control sequences
– 2-pipe (ON/OFF)
– 2-pipe (ON/OFF) with el. heater (ON/OFF)
– 2-pipe (ON/OFF) and radiator (ON/OFF)
– 4-pipe (ON/OFF)
– 2-stage (ON/OFF) heating or cooling
RDG110
RDG140
Thermostat for mod. control
sequences with (DC 0...10 V)
output signals
– 2-pipe (DC 0...10 V)
– 2-pipe (DC 0...10 V) with el. heater (DC 0...10 V)
– 2-pipe (DC 0...10 V) and radiator (DC 0...10 V)
– 4-pipe heating (DC 0...10 V) and cooling (DC 0...10 V)
– 2-stage (DC 0...10 V) heating or cooling
RDG140
RDG160
Thermostat for mod. control
sequences with (DC 0...10 V)
output signals for valves and
fan control (ECM) DC 0...10 V
– 2-pipe (DC 0...10 V)
– 2-pipe (DC 0...10 V) with el. heater (DC 0...10 V)
– 2-pipe (DC 0...10 V) and radiator (DC 0...10 V)
– 4-pipe heating (DC 0...10 V) and cooling (DC 0…10 V)
– 2-stage (DC 0...10 V) heating or cooling
RDG160
Semi flush-mounted units: RDF
RDF300../400…*
Versatile thermostats with
relay ouputs: ON/OFF or 3-pos.
– 2-pipe
– FCU: (ON/OFF or 3-pos)
– 2-pipe (ON/OFF) with el. heater (ON/OFF)
– 4-pipe (ON/OFF)
RDF300... RDF400... RDF301...
RDF310…/410..*
Basic thermostats for 2-pipe
application
– 2-pipe (ON/OFF)
RDF310… RDF410.21
RDF340
Thermostat for mod. control
sequences with (DC 0...10 V)
output signals
– 2-pipe (DC 0...10 V)
– 2-pipe (DC 0...10 V) with el. heater (DC 0...10 V)
– 4-pipe heating (DC 0...10 V) and cooling (DC 0...10 V)
RDF340
*Variants
RDF300 Basic version
RDF300.02 Unit with backlight
RDF300.02/SL Unit with backlight, silver
RDF400.01 Basic version
RDF400.01/SL Unit with backlight, silver
RDF301 Communicating unit
RDF301.50 Communicating unit with 4 buttons for light and shutter
RDF310.2 Basic version
RDF310.21 Basic version with backlight and infrared remote control
RDF410.21 Basic version with backlight, 7-day time program and infrared remote control
