Application Type of control outputs
RDG…
Wall-mounted range
Chilled/heated ceiling and radiator
Chilled/heated ceiling (ON/OFF) and radiator (ON/OFF) RDG100... RDG110
Chilled/heated ceiling (ON/OFF) and radiator (mod. PWM or 3-pos.) RDG100...
Chilled/heated ceiling mod. (PWM) and radiator (ON/OFF, PWM or 3-pos.) RDG100...
Chilled/heated ceiling mod. (3-pos.) and radiator (ON/OFF, PWM or 3-pos.) RDG100...
Chilled/heated ceiling mod. (DC 0...10 V) and radiator (DC 0...10 V) RDG140
Chilled ceiling and radiator
Chilled ceiling (ON/OFF) and radiator (ON/OFF) RDG100... RDG110
Chilled ceiling (ON/OFF) and radiator (mod. PWM or 3-pos.) RDG100...
Chilled ceiling (PWM) and radiator (ON/OFF, PWM or 3-pos.) RDG100...
Chilled ceiling (3-pos.) and radiator (ON/OFF, PWM or 3-pos.) RDG100...
Chilled ceiling (DC 0...10 V) and radiator (DC 0...10 V) RDG140
Chilled/heated ceiling 2 stage cooling or 2-stage heating
2-stage (ON/OFF) heating or cooling RDG100... RDG110
2-stage mod. (PWM) heating or cooling RDG100…
2-stage mod. (3-pos.) heating or cooling RDG100…
2-stage mod. (DC 0...10 V) heating or cooling RDG140
Abbreviation
ON/OFF: 2-position control
3-pos.: Modulating 3-position control signal
PWM: Pulse Width Modulation control signal
DC 0...10 V: Modulating DC 0...10 V control signal
el. heater: Electrical heater
mod. output: Modulating output
