Siemens RUGGEDCOM RS910 User Manual

Technical Specifications
5.6Serial Port Specifications
Tx (dBm)
Mode
Connector
Type
Tx λ
(nm)
a
Cable
Type (μm)
Minimum Maximum
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(km)
a
Power
Budget
(dB)
SM LC 9/125 1300 -5 0 -35 3 50 30
SM SC 9/125 1300 0 5 -37 0 90 37
SM LC 9/125 1300 0 5 -37 0 90 37
MM LC 50/125 1300 -22.5 -14 -31 -14 2 8.5
a
Typical.
5.6 Serial Port Specifications
The following details the specifications for serial ports that can be ordered with the
RUGGEDCOM RS910.
Copper Serial Ports
Baud Rate 300 to 230 kbps
Connector DB9 or RJ45
Isolation 2.5 kV
Fiber Serial Ports
Mode Multimode
Connector ST
Typical Distance (km) 5
Optical Wavelength
(nm)
820
Cable Size 50/125 or 62.5/125
5.7 Operating Environment
The RUGGEDCOM RS910 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
a
-40 to 85 °C (-40 to 185 °F)
Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F)
Ambient Relative Humidity
b
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
32
RUGGEDCOM RS910
Installation Manual, 04/2021, C79000-G8976-1029-12
