Siemens RUGGEDCOM RSG909R User Manual

Introduction
1.3Required Tools and Materials
1
POWER LED
2
ALARM LED
3
USB Console Port
4
RNA Port (Port A/B)
5
Port 7
6
Copper Ethernet Ports (Ports 1 to 6)
7
Failsafe Alarm Relay
8
Power Supply Terminal Blocks
9
Chassis Ground Screw
Figure1.1 RUGGEDCOM RSG909R
POWER LED Illuminates green during boot up and when power is supplied to the
device.
ALARM LED Illuminates red when an alarm condition exists.
Console Port The USB Type-B console port is for interfacing directly with the
device and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page 25)".
Communication Ports Communication ports in general receive and transmit data, as
well as provide access to the RUGGEDCOM ROS Web interface.
For more information about the various ports available, refer to
"Communication Ports (Page 27)".
Failsafe Alarm Relay Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 12)"
• "Failsafe Alarm Relay Specifications (Page 32)"
Power Supply Terminal Blocks Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to "Connecting Power (Page
14)" and "Power Supply Specifications (Page 31)".
Chassis Ground Terminal Protects the device from power surges and accumulated static
electricity. For information about grounding the device, refer to
"Connecting Power (Page 14)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM RSG909R:
Tools/Materials Purpose
AC power cord (16 AWG) For connecting power to the device.
USB Type-B console port cable For connecting to the RUGGEDCOM ROS console
interface.
CAT-5 Ethernet cables For connecting the device to a LAN.
Flathead screwdriver For mounting the device to a DIN rail.
Phillips screwdriver For mounting the device to a panel.
Torx screwdriver For attaching mounting brackets to the device.
4 x M5 or #10-24 screws For mounting the device to a panel.
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
3
