Technical Specifications
5.6Mechanical Specifications
5.6 Mechanical Specifications
Weight 2.4 kg (5.3 lbs)
Ingress Protection IP40
Enclosure Die Cast Aluminum
5.7 Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
90
176.52
162.72
Figure5.1 Overall Dimensions
34
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
