Siemens RUGGEDCOM RSG909R User Manual

Certification
6.2EMC and Environmental Type Tests
Test Description Test Levels Severity
Levels
IEC
61000-4-9
Pulse Magnetic Field Enclosure
Ports
300 A/m 4
IEC
61000-4-11
Voltage Dips and Interrupts AC Power
Ports
30% for 0.5 Cycles
60% for 5 Cycles
100% for 250 Cycles

Signal Ports 30 V Continuous
300 V for 1 s
4IEC
61000-4-16
Mains Frequency Voltage
DC Power
Ports
30 V Continuous
300 V for 1 s
4
IEC
61000-4-17
Ripple on DC Power Supply DC Power
Ports
15% 4
IEC
61000-4-18
Damped Oscillatory Wave Slow
Damped
2.5 kV Common
100 kHz or 1 MHz
3
IEC
61000-4-29
Voltage Dips and Interrupts DC Power
Ports
30% for 0.1 s
60% for 0.1 s
100% for 0.05 s

Signal Ports 2 kV (Failsafe Relay Output) 
DC Power
Ports
2 kV or 2.8kV DC 
Dielectric Strength
AC Power
Ports
2 kV 
Signal Ports 5 kV (Failsafe Relay Output) 
DC Power
Ports
5 kV 
IEC
60255-27
HV Impulse
AC Power
Ports
5 kV 
EMC Immunity Type Tests per IEEE 1613
Note
The RUGGEDCOM RSG909R meets Class 2 requirements for an all-fiber
configuration and Class 1 requirements for copper ports. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
Test Description Test Levels
Enclosure Contact ± 8 kVIEEE 1613 ESD
Enclosure Air ± 15 kV
IEEE 1613 Radiated RFI Enclosure Ports 35 V/m
Signal Ports ± 4 kV @ 2.5 kHz, 5 kHz
DC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz
AC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz
IEEE 1613 Fast
Transient
Earth Ground Ports ± 4 kV
RUGGEDCOM RSG909R
Installation Manual, 02/2021, C79000-G8976-1388-12
43
