Siemens SCALANCE X-300 Series Configuration Manual

Configuration using Web Based Management and Command Line Interface
4.5 The Switch menu
SCALANCE X-300 / X-400
150 Configuration Manual, 10/2014, C79000-G8976-C187-22
Slot / Port
You have the option of adding specific ports to the link aggregation or removing them from it.
You can only modify ports that are not members of another link aggregation.
The meaning is as follows:
● M (black): The port is a member of the aggregation.
● M (blue): The port is a member of the aggregation and is its master port.
Changing the master port
To change the master port, follow the steps below:
1. Click on the original master port (blue M) - the marking disappears. If you want to keep
the port in the aggregation, click on it a second time (black M)
2. Click on the new master port until a blue M appears.
Syntax of the Command Line Interface
Current Link Aggregation - CLI\SWITCH\LAG>
Command
Description
Comment
info
Shows the current settings of the link aggregation
group (actual status).
-
frmdistr [mode] Sets the type of distribution of packets on the
individual links of an aggregation.
The following modes exist for X414:
• srcmac
source MAC address
• dstmac
destination MAC address
• mac
source and dest. MAC address
• srcip
source IP address
• dstip
destination IP address
• ip
source and dest. IP address)
The following modes exist for X408/X-300:
• hash
source and dest. MAC address hash
• xor
source and dest. MAC address Xor
Administrator only.
add <masterport> Creates a new link aggregation with the specified
master port
Administrator only.
