LCD-MonitorSCD1297



Page4/19



DOC-No.:B30071D1.DOC



1 Overview

The LCD monitor SCD 1297 has been developed and constructed especially for industrial

pplications. This monitor can be used in applications where a standard CRT-device would be

unsuitable, due to space or environmental restrictions. Its compact enclosure opens up a wide

spectrum of possible application areas for the SCD 1297, ranging from air-conditioned computer

roomsbehindaswitchingcabinetdoor,totheimmediatevicinityofmachineryinaspecialprotective

enclosure.Asisthecaseforallindustrialsystems,themonitorhasbeendesignedtowithstandthe

particulardemandsplaceduponsuchequipment,e.g.,itisimmunetoelectromagneticradiationand

canwithstandalargetemperaturerange.

Thetrend-settingLCDtechnologyinthismonitorhasrelegatedpicturegeometrydistortionandcolour

patchestothepast.Evenatthelowrefreshrateof50Hz.thescreenremainsflicker-free.TheSCD

1297thusfulfilseventhestrictestergonomicrequirements.Picturesoflowerresolutionareexpanded

tofillthescreen.



TheSCD1297cansimultaneouslydisplayupto262144coloursenablingrealisticcolourimagesand

videostobedisplayed.TheLCD-monitorcontainsspecialhardwaretoconvertastandardanalogue

VGAvideosignalforthedisplaycontroller.CompatibilitywithconventionalCRTmonitorsis,thus,

guaranteed.



ItisveryeasytoadjustthemonitorsettingsusingtheclearlydesignedOSD(OnScreenDisplay).The

“AutomaticAlignment”functiondoesawaywiththeneedtocarryouttediousadjustmentssuchas

picture position and phase. At the press of a button, the monitor performs these alignments

automatically.



TheSCD1297isequippedwithanactive12.1”TFTdisplaymodulewithamaximumresolutionof

800x600 pixels. The integrated power management system VESA DPMS, allows a significant

reduction in power consumption when the synchronisation signal from the computer has been

switchedoff,comparedwiththatunder“normal”operation.



Threeversionsofthemonitorareavailable:



stand-alonechassis   SCD1297-C(CTwithTouch)

mountablewithfrontplate  SCD1297-E(ETwithTouch)

19“rack6HE  SCD1297-R(RTwithTouch)


