1.2.1Instructions for Handling Assemblies Susceptible to
E
lectrostaticShock
Most of the assemblies within the SCD 1297 LCD-monitor contain components which can be
destroyedbyelectrostaticvoltages.Itisalsopossiblefortheassembliestobedamagedinsucha
waythattotalfailuredoesnotoccur.

If you (as an authorised service technician) are handling such assemblies then the following
precautionsshouldbeobserved:

Whensuchassembliesarebeinghandled,ameansofelectrostaticdischargemustbeavailable.This
canbe,forexample,anearthedobject,whichcanbetouchedtodischargeelectrostaticvoltages.
Thisappliestoalltoolsused(insulated).Theymustalsobedischargedatanearthedobject.
Whenassembliesareremovedoraddedtothesystem,theunitmustalwaysbeswitchedoffandthe
powersupplycabledisconnected.
Vulnerableassembliesshouldalwaysbeheldbytheiredge.Avoidtouchingtracksandcontactpins.

2 GeneralInstallation
PreparationforinstallingtheLCD-monitorincludethefollowingpoints:

Removalofallpackaging

Checkingofcomponentsfordamage

Comparisonofcomponentsreceivedwiththoseonthedeliverynote

Connectiontothecomputersystemandpowersupply

Buildingintoyoursystem,bearinginmindtechnicalandergonomicaspects

2.1 RemovingthePackagingandCheckingIndividualParts

After unpacking all the delivered components, they should be checked for completeness and for
possibletransportdamage(visualinspection).Ifanydeficienciesarefoundthenpleasecontactthe
servicedepartmentgivenonthedeliverynote.Havethedeliverynotenumber,serialnumberanda
descriptionofthedeficiencytohand.

Theoriginalpackagingshouldbekeptforfuturetransportation.
