LCD-MonitorSCD1297
Page8/19
DOC-No.:B30071D1.DOC
A
147
41
307
329
154.5
319
111
229
40
76
5x20
ACTIVEAREA246x184.5
2.2 InstallingtheLCD-Monitor
TwofixingbracketscanbeusedtomounttheSCD1297-C(CT)behindafrontplate.
TheSCD1297-E(ET)isdeliveredtogetherwithafrontplate.Ithasasealingbandallthewayround.
Whenmountingthefrontplate,caremustbetakentoensurethattheO-ringremainsinitsgroove
otherwisethesealmaynotbetight.
TheSCD1297-R(RT)isdesignedformountinginastandard19“racksystem.Supportingrailsarenot
necessary.
Figure1:DimensionsoftheSCD1297-C/CT
