Siemens SDV7 User Manual

50
Table 15: Technical ratings
Item Unit 15.5 kV 27.6 kV 38.0 kV
Lightning impulse withstand voltage
Full wave 1.2/50 µs
Chopped wave 2 µs
1
Chopped wave 3 µs
kV
110
142
----
150
194
----
200
258
----
Power-frequency withstand voltage kV 50 60 80
Rated short-circuit current kA 20/25/31.5/40 20/25 20/25/31.5/40
%dc component % 48 48 48
Rated closing and latching current kA peak 52/65/82/104 52/65 52/65/82/104
Rated duty cycle
Reclosing duty
Non-reclosing duty
---- O-0.3 s-CO-3 min.-CO
O-15 s-CO
O-0.3 s-CO-3
min.-CO
O-15 s-CO
O-0.3 s-CO-3 min.-CO
O-15 s-CO
Minimum reclosing time
2
s 0.3 0.3 0.3
Rated power frequency Hz 60 60 60
Capacitance switching
Overhead line
Isolated bank
Back-to-back
A
100
400
400
100
400
400
100
250
250
Phase spacing
(bushing center-to-center)
1,200 A
2,000 A
3,000 A
inches (mm) 13.0 (330)
13.0 (330)
16.0 (406)
16.0 (406)
16.0 (406)
----
19.5 (495)
19.5 (495)
2,500 A 19.5 (495)
External creep inches (mm) 25.2 (640) 26.5 (673) 41.0 (1,040)
External strike-to-ground inches (mm) 10 (255) 10 (255) 17 (480)
Operating temperature range
Standard
Optional
°C -30 to +40
-40 to +40
3
-30 to +40
-40 to +40
3
-30 to +40
-40 to +40
3
Operating mechanism ----
Stored-energy/
magnetic-actuator
Stored-energy/
magnetic-
actuator
Stored-energy/
magnetic-actuator
Closing time
4
ms ≤65/≤55 ≤65/≤55 ≤70/----
Opening time by interrupting time
4
Three-cycle
Five-cycle
ms ≤38/≤33
≤56/----
≤38/≤33
≤56/----
≤38/----
≤56/----
Dual trip coils (mechanically and electrically
independent)
----
Optional
(stored-energy)
Optional
(stored-energy)
Optional
(stored-energy)
Auxiliary voltages (options)
Close, trip and protection
Space heaters, auxiliaries
----
Vac
See Table 11
120/240
See Table 11
120/240
See Table 11
120/240
Contact gap (stroke)
Vacuum interrupter type
1,200 A
2,000 A
3,000 A
mm
20/25
VSS-17006
7-9
7-9
----
20/25
VS-25008
13-15
13-15
----
31.5/40
VS-15052
7-9
7-9
7-9
VS-25008
13-15
13-15
----
VS-30030
18-22
18-22
(2,500) 18-22
VS-30041
18-22
18-22
18-22
Radio influence voltage (RIV) 1,000 kHz μV ≤500 ≤650 ≤650
Seismic withstand (optional) (ANSI/IEEE 693-
2005 high-response spectrum)
g 0.5 0.5 0.5
Footnotes:
1
Circuit breaker is in closed position.
2
User must supply external time delay (typically using setting in reclosing relay) for the minimum reclose time interval of 0.3 s in accordance with
ANSI/IEEE.
3
Consult factory for -50 °C.
4
First value is for stored-energy operator; value after slash is for magnetic-actuator operator. For magnetic-actuator operator, add 10 ms if
command power is ac.
