Accessories
4.3 Connection system
3VA molded case circuit breakers with IEC certificate
270 Manual, 03/2019, A5E03603177010-03
All wire connectors can be ordered with control wire tap under a separate article number.
The wire connector is then supplied with a hole for the control wire tap. A ring terminal can
be installed in this hole. The screw required is supplied.
Control wire tap for box terminal
This control wire tap is inserted in the box terminal with the cable.
The following connections can be selected for the control wire tap:
