Technical specifications

6.4 Derating and temperature compensation

3VA molded case circuit breakers with IEC certificate

642 Manual, 03/2019, A5E03603177010-03

3VA2 molded case circuit breakers, fixed-mounted versions

Only the COM060 communication module has an effect on derating. Other internal accessories can be used

without restriction.

COM060 COM060 communication module

No derating up to the rated operational current I

of the molded case circuit breaker
