Memory concept
4.1 Memory areas and retentivity
CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
4-5
Address areas of system memory
Table 4-4 Address areas of system memory
Address areas Description
Process image of inputs At every start of an OB1 cycle, the CPU reads the values at the
input of the input modules and saves them the process image of
inputs.
Process image of outputs During its cycle, the program calculates the values for the outputs
and writes these to the process image of outputs. At the end of
the OB1 cycle, the CPU writes the calculated output values to the
output modules.
Flag bits This area provides memory for saving the intermediate results of
a program calculation.
Timers Timers are available in this area.
Counters Counters are available in this area.
Local data Temporary data in a code block (OB, FB, FC) is saved to this
memory area while the block is being edited.
Data blocks See
Recipes and measurement value logs
Reference
The address areas of your CPU are listed in the
Instruction list for CPUs 31xC and 31x
.
I/O process image
When the user program addresses the input (I) and output (O) address areas, it does not
query the signal states of digital signal modules. Instead, it rather accesses a memory area
in CPU system memory. This particular memory area is the process image.
The process image is organized in two sections: The process image of inputs, and the
process image of outputs.
Advantages of the process image
Process image access, compared to direct I/O access, offers the advantage that a consistent
image of process signals is made available to the CPU during cyclic program execution.
When the signal status at an input module changes during program execution, the signal
status in the process image is maintained until the image is updated in the next cycle.
Moreover, since the process image is stored in CPU system memory, access is significantly
faster than direct access to the signal modules.
Process image update
The operating system updates the process image periodically. The figure below shows the
sequence of this operation within a cycle.
