SIMATIC 545/555/575 System Manual
Preface
This SIMATIC 545/555/575 System Manual includes requirements and
specifications for preparing your control site and installing a
SIMATICr 545, 555, or 575 programmable logic controller system.
This manual describes the following equipment:
• 545–1103, –1104, –1105, and –1106 CPUs
• 555–1103, –1104, –1105, and –1106 CPUs
• 575–2104, –2105, and –2106 CPUs
• 575–2126 Remote I/O Annex Card
• 505–CP5434–DP Remote I/O Annex Card
• 505–6851–A/B Remote Base Controllers
• 505–6850–A/B Remote Base Controllers
• 505–6870 PROFIBUS-DP Remote Base Controller
The following major topics are covered:
• Site preparation, including power and grounding requirements and
other safety considerations.
• Hardware installation, including Series 505t and VMEbus bases,
power supplies, 545/555/575 CPUs, remote base controllers (RBCs),
I/O modules, and annex cards.
• System cable and wiring procedures.
• System startup, including modem operation.
• System troubleshooting, including use of AUX functions, status words,
and other diagnostic aids.
• General maintenance procedures, such as changing power supply fuses.
• Using EEPROMs and EPROMs.
• Upgrade of Series 500t bases for connection to the 545/555.
The material about 575 interboard communication which was formerly
located in the SIMATIC TI575 System Manual has been moved to an
appendix of the SIMATIC 545/555/575 Programming Reference User
Manual.
