Page #20 background imageLoading...
Page #20 background image
C7-Ein-/Ausgabebaugruppe / C7 Input/Output Module
20
Produktinformation
/ Product Information
C79000-Z7074-C630-01
The
C7 input/output module is currently not included in the hardware catalog of the
STEP7
hardware
configuration. T
o configure the C7 input/output module, copy the
I/O
from slots 4 and 5 of a C7-63x/P
project to slots 6 and 7 (in the case of connec
-
tion to a C7-62x or C7-63x/P) or to slots 4 and 5 (in the case of connection to a
C7-63x DP):
C7-623/P, C7-624/P, C7-626/P, C7-626/P DP,
C7-633/P, C7-634/P
with C7 Input/Output Module
C7-623/A, C7-626/A, C7-633 DP, C7-634 DP
with C7 Input/Output Module
S Create C7-63x/P configuration
(up to V4.02 update setup required, accompa-
nying floppy disk or FAQ on Internet)
S Select module slot 4
Edit
"
Copy
S Select module slot 6
Edit
"
Paste
S Select module slot 5
Edit
"
Copy
S Select module slot 7
Edit
"
Paste
S Create C7-6xx configuration with I/O of the
basic device
S Set up temporary STEP7 project and create
C7-633/P configuration
(up to V4.02 update setup required, accompa-
nying floppy disk and FAQ on Internet)
S Select module slot 4 in temporary project
Edit
"
Copy
Select
slot 4 or 6 in the project of the basic de
-
vice
Edit
"
Paste
S Select slot 5 in the temporary project
Edit
"
Copy
Select module slot 5 or 7 in the project of the
basic device
Edit
"
Paste
S Delete 2nd temporary STEP7 project
Configuration
in
STEP 7
