C7-Ein-/Ausgabebaugruppe / C7 Input Output Module
31
Produktinformation
/ Product Information
C79000-Z7074-C630-01
Basic
circuit
diagram of the digital inputs
24
V
1L+
M
internal
1M
Basic circuit diagram of the digital outputs
2L+
2M
Bild 1-15 Basic Circuit Diagrams of the Digital Inputs/Outputs
