Technical specifications
8.4 Specifications
Basic Panels
134 Operating Instructions, 04/2012, A5E02421799-03
Interfaces
KTP400 Basic
mono PN
KTP400 Basic
color PN
KTP600 Basic
mono PN
KTP600 Basic
color DP
KTP600 Basic
color PN
1 x RS 422/RS 485 - - - Max. 12 Mbps -
1 x Ethernet RJ45 10/100 Mbps - 10/100 Mbps
Supply voltage
KTP400 Basic
mono PN
KTP400 Basic
color PN
KTP600 Basic
mono PN
KTP600 Basic
color DP
KTP600 Basic
color PN
Rated voltage
Range, permissible
+24 V DC
19.2 to 28.8 V (–20%, +20%)
Transients, maximum
permissible
35 V (500 ms)
Time between two
transients, minimum
50 s
Current consumption
• Typical
• Constant current,
maximum
• Inrush current I
2
t
Approx. 100 mA
Approx. 150 mA
Approx. 0.5 A
2
s
Approx. 100 mA
Approx. 120 mA
Approx. 0.5 A
2
s
Approx. 240 mA
Approx. 350 mA
Approx. 0.5 A
2
s
Approx. 350 mA
Approx. 550 mA
Approx. 0.5 A
2
s
Fuse, internal Electronic
Miscellaneous
KTP400 Basic mono PN KTP600 Basic mono
PN
KTP600 Basic color
DP
KTP600 Basic color
PN
Software clock,
synchronizable
Yes
