Mounting and connecting
3.1 Preparations
Basic Panels
32 Operating Instructions, 04/2012, A5E02421799-03
Mounting compatibility
The mounting cutouts of the Basic panels are compatible with the mounting cutouts of the
following SIMATIC HMI devices:
Mounting cutout for the Basic
Panel
Compatible to the mounting cutouts of the HMI device
KP400 Basic OP77A, OP77B
KTP400 Basic TP 177B 4"
KTP600 Basic TP 177 A, TP 177B 6", TP 177micro
KTP1000 Basic MP 277 10" Touch, MP 377 12" Touch
TP1500 Basic MP 377 15" Touch, Thin Client 15" Touch
Dimensions of the mounting cutout
w
h
Dimensions of the mounting cutout for the
basic HMI devices in horizontal mounting position:
+1
0
+1
0
.73%DVLF
.73%DVLF
73%DVLF
.73%DVLF
w
h
.3%DVLF
.3%DVLF
Dimensions of the mounting cutout for the
basic HMI devices in vertical mounting position:
+1
0
+1
0
.73%DVLF
.73%DVLF
w
h
All dimensions in mm
See also
Accessories (Page 23)
