Siemens SIMATIC HMI Manual

1 2 3 4 5 6 7 8 9 10 Meaning
on on on on on off on on MCP address 223
off on on on on off on on MCP address 222
on off on on on off on on MCP address 221
off off on on on off on on MCP address 220
on on off on on off on on MCP address 219
off on off on on off on on MCP address 218
on off off on on off on on MCP address 217
off off off on on off on on MCP address 216
on on on off on off on on MCP address 215
off on on off on off on on MCP address 214
on off on off on off on on MCP address 213
off off on off on off on on MCP address 212
on on off off on off on on MCP address 211
off on off off on off on on MCP address 210
on off off off on off on on MCP address 209
off off off off on off on on MCP address 208
on on on on off off on on MCP address 207
off on on on off off on on MCP address 206
on off on on off off on on MCP address 205
off off on on off off on on MCP address 204
on on off on off off on on MCP address 203
off on off on off off on on MCP address 202
on off off on off off on on MCP address 201
off off off on off off on on MCP address 200
on on on off off off on on MCP address 199
off on on off off off on on MCP address 198
on off on off off off on on MCP address 197
off off on off off off on on MCP address 196
on on off off off off on on MCP address 195
off on off off off off on on MCP address 194
on off off off off off on on MCP address 193
off off off off off off on on MCP address 192
x x x x x x x x "
on off off off off off off off MCP address 001
off off off off off off off off MCP address 000
Interfaces
4.3 Machine control panels
ERGOline Stage 3
32 Manual, 02/2015, 6FC5397-4FP40-0BA0
